Mister Hitches SKU: MH-ABM-5XHD

Mister Hitches 4000kg Adjustable Ball Mount 12 Stage

Adjustable & Fully Reversible - 12 Stages Both Sections Of This Hitch Can Be Inverted. 6 Stages Of Drop -...
    Sale price $237.00Regular price
    Regular price $237.00
    Tax included. Shipping calculated at checkout.

    Low stock

    Mister Hitches 4000kg Adjustable Ball Mount 12 Stage
    Sale price $237.00Regular price
    Regular price $237.00

    Mister Hitches 4000kg Adjustable Ball Mount 12 Stage

    Mister Hitches 4000kg Adjustable Ball Mount 12 Stage
    • Adjustable & Fully Reversible - 12 Stages
    • Both Sections Of This Hitch Can Be Inverted.
    • 6 Stages Of Drop - 80mm/110mm/130mm/140mm/160mm/190mm
    • 6 Stages Of Rise - 50mm/80mm/105mm/110mm/135mm/165mm
    • 10mm Dual Support Gussets For Added Strength
    • New Model With 3 Pin Holes (Ranger Short Shank Compatible)
    • Uses 12.9 Grade High Tensile 16mm Bolts - Torque To 189nm
    • 25mm X 75mm Heavy Duty Ball Platform.
    • Matt Black Seaguard Finish
    • Robotic Welded For Consistent Quality
    • Cnc Machined For Maximum Accuracy
    • Fits 2" X 2" Towbar Receivers
    • Complies With The Test Requirements Of Adr62/02
    • Gross Trailer Weight: 4000kg

    Tongue Weight: 400kg

    Ball Hole Size: 7/8"

    Max Drop: 190mm

    Max Rise: 165mm

    Lengths: (Measured From Centre Of Pin Hole To Centre Of Ball Hole) 266/305/331mm

    Pin Holes To End Of Shank 50mm, 76mm, 115mm

    End Of Shank To Gusset 164mm

    Suits Stone Stomper & Most Couplings Eg. D035
