Introducing ScanGauge-3
All The Features You've Been Asking For
ScanGaugeIII can help you monitor your vehicle’s most vital systems and provide the kind of real-time information you’ve been missing. Features include built-in digital gauges, 5 sets of trip data and an easy-to-use Scan Tool that shows both set and pending trouble codes — all in an ultra compact design that installs in minutes.
The new ScanGauge-III features capacitive touch screen with over 16 million possible colours, audible and visual alarms, automatic X-Gauge configuration and configurable gauges display for up to 9 gauges on each screen saved to your preference.
OBD2 DIGITAL GAUGES
ScanGaugeIII provides real-time gauges to show you what is going on “under the hood” with built-in digital gauges. The gauge screen allows you to select and display up to 9 gauges at a time, so you can monitor the current operating conditions of your vehicle in real-time. Customise the number of gauges and pages to your preference.
| Gauge |
Name |
| AVG |
Average Fuel Economy |
|
CLSD LP / OPEN LP
|
Fuel System Loop Status |
| CPM |
Cost Per Mile/KM |
|
FIA / CIA
|
Intake Air Temperature |
| FPR |
Fuel Pressure |
|
FWT / CWT
|
Water Temperature |
|
GPH
LPH
|
Gallons Per Hour
Litres Per Hour
|
|
MAP
BST
|
Manifold Absolute Pressure
Boost
|
|
MPG
KPG
MPL
LHK
KPL
|
Miles Per Gallon
Kilometers Per Gallon
Miles Per Litres
Liters Per 100Km
Kilometeres Per Liter
|
|
MPH
KPH
|
Miles Per Hour
Kilometers Per Hour
|
| RPM |
Revolutions Per Minute |
| TFC |
Trip Fuel Cost |
| TPS |
Throttle Position Sensor |
| VLT |
Battery Voltage |
| IGN |
Ignition Timing |
| LOD |
Engine Loading |
| HPR |
Horsepower |
ScanGauge-III provides real-time data about your vehicle’s instant and average fuel economy, fuel used, cost of fuel used for each trip, cost per KM, Litres per hour and more!
There are many ways to reduce your fuel usage and increase fuel economy. Real time feedback like what the ScanGauge provides is one of the most effective.
- Driving More Efficiently With ScanGauge Can Save Up to 33%
- Removing Excess Weight and Drag can save up to 17%
- Simply Observing the Speed Limit can save up to 14%
- Avoiding Excessive Idling can save up to 2%
*The information available may vary depending on vehicle's make and model. If the information is not available no data will be shown for it. If the same gauge is selected for more than one position, only one of them will show data.
Trip Computers
With five built-in trip computers, the ScanGauge can keep track of everything from fuel cost to distance traveled and everything in between. Data is stored on the ScanGauge and is retained even when the power is disconnected. Each trip computer starts automatically and information is available anytime during the trip.
Engine OBD2 Scan Tool
The ScanGauge can check for Engine Diagnostic Trouble Codes (DTCs) and if found, can display how many there are and the Trouble Codes themselves and their meanings. Using the internet or repair manuals, these can be translated to the failed component and repairs can be made.
- Reads Trouble Codes
- Clears Trouble Codes
- Shows Conditions When Trouble Was Detected (RPM, COOLANT, TEMP etc)
- Turns Off “CHECK ENGINE” Light
- Shows When Onboard Tests Have Been Completed And Vehicle Is Ready To Pass OBDII emissions Testing
Great Features
Easy to Install No Tools Required
Installs in just minutes without tools. Simply plug the ScanGauge into the diagnostic connection under the dash.
No Batteries Required
The single connection to the diagnostic connector under the dashboard is all that is needed.
Automatic Protocol Determination
ScanGauge automatically determines the protocol your vehicle uses and connects.
6-Foot Cord and Suction Cup Windshield Mount
The ScanGauge can be mounted up to 6 feet (1.8 Meters) from the under-dash diagnostic connector. The included Suction Cup Windshield Mount allows the ScanGauge to be quickly detached and then used to troubleshoot other vehicles.
User-Friendly Capacitive Touch Display
Simple touch operation allows you quickly and easily access the powerful features of the ScanGauge. Swiping two fingers up or down will raise and lower the brightness
Colour Backlight Display
Match your instrument panel for an integrated look.
English & Metric Units
The Digital Gauges and Trip Computer information can be shown in either English or Metric units of measure, including KM’s, Litres, Celsius, and kPA.
Compact Design
Unit Dimensions 12.7 x 8.1 x 2.55 cm
Package Includes
ScanGauge-3 Unit
ScanGauge cable (1.8m)
Suction Cup Mount
